A brass swing check valve is a non-return valve that uses a hinged disc to allow fluid flow in one direction only, automatically closing to block reverse flow and protect pipelines from backflow and water hammer. SWBM Dubai supplies the MIHA Brass Swing Check Valve, a PN16-rated, BSPT threaded valve manufactured from high-grade brass for excellent corrosion resistance and long-term reliability across residential, commercial, and industrial applications in Dubai, Sharjah, Abu Dhabi, and the wider UAE.
Key features:
- Swing disc mechanism allows one-way flow and closes automatically to stop backflow
- Solid brass body for corrosion resistance and long service life
- BSPT threaded connection with standard dimensions for quick, leak-free installation
- PN16 pressure rating for consistent performance under load
- Ideal for water supply systems, irrigation networks, plumbing installations, HVAC lines, industrial processes, and agricultural applications
SWBM Dubai keeps this brass swing check valve in ready stock across sizes 1/2″ to 4″, ensuring fast turnaround on both small plumbing orders and large industrial project requirements.
Need this valve urgently? SWBM Dubai, your trusted Brass Threaded Valve supplier in Dubai, UAE, keeps stock ready for immediate dispatch. Enquire now for best pricing of brass swing check valve and same-day quotation.
| Size(inch) | 1/2″ | 3/4″ | 1″ | 1-1/4″ | 1-1/2″ | 2″ | 2-1/2″ | 3″ | 4″ |
|---|---|---|---|---|---|---|---|---|---|
| DN(mm) | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 |
| L(mm) | 47 | 51.5 | 63 | 70 | 82 | 97 | 120 | 133 | 160 |
| H(mm) | 48 | 54 | 61.5 | 73 | 80 | 95 | 115 | 131 | 158.5 |
